Inconel 800/800H/800HT Coils Manufacturers, Inconel 800/800H/800HT Coils Exporters, Inconel 800/800H/800HT Coils Suppliers, Inconel 800/800H/800HT Coils Importers , Inconel 800/800H/800HT Coils Stockists
Inconel 800/800H/800HT Coils Manufacturers in Mumbai, Inconel 800/800H/800HT Coils Exporters in Mumbai , Inconel 800/800H/800HT Coils Suppliers in Mumbai, Inconel 800/800H/800HT Coils Importers in Mumbai , Inconel 800/800H/800HT Coils Stockists in Mumbai
Inconel 800/800H/800HT Coils Manufacturers in India, Inconel 800/800H/800HT Coils Exporters in India, Inconel 800/800H/800HT Coils Suppliers in India, Inconel 800/800H/800HT Coils Importers in India , Inconel 800/800H/800HT Coils Stockists in India
Inconel 800 Slatting Coil, Inconel 800 Circle, Incoloy Alloy 800H Coils, 800HT Incoloy Hot Rolled Coils Supplier in Mumbai, India. Incoloy 800 Circle, Incoloy Werkstoff Nr. 1.4876 Coils Dealer in India. 800HT Incoloy Polished Cold Drawn Plates, 800 Incoloy Plate Stockholder, Distributors Of ASME SB409 Incoloy 800H Coils, Incoloy GOST ЭИ670 Strips Stockist, Manufacturer.
Incoloy 800 Coils are security from stretched out preface to high temperatures. Incoloy 800H Sheets is especially practical as it keeps up a dependable improvement, despite when unprotected to taking off temp.
In the interim, these Incoloy 800H Plates are correspondingly being offered in different sizes and shapes to our customers. Incoloy 800HT Coils perform well in sodium salt and other fluid salt conditions, with stress utilize part square beating standard austenitic set steels.
Incoloy 800 Slatting Coils has splendid impenetrable to oxidation and carburization in high temperature conditions. Incoloy 800HT Perforated Coils has an obliged science, inside the cutoff inspirations driving Incoloy 800H Perforated Coils, and requires a glimmer treatment of 2100 Degree F (1149 Degree C) least.
Inconel 800HT Coils is in like manner used for valves, fittings and various parts familiar with hazardous device from 1100 Degree F to 1800 Degree F. Blend 800 Sheets Plates with a standard temper is recommended for relationship underneath 1100 Degree F (600 Degree C)
Inconel 800/800H/800HT Coils Specifications
| Specifications | : | ASTM / ASME SB 409 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Equivalent Grades for 800/800H/800HT Inconel Coils
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
Inconel 800/800H/800HT Coil Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
Inconel 800/800H/800HT Coil Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Inconel 800/800H/800HT Coils Applications
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceutical
- EquipmentSea Water
- EquipmentPulp and Paper Industry
