SB 265 gr 3, CP Grade 3 Titanium Plate and Titanium Cp Grade 3 Strip distributor in India, Buy Titanium CP2 Grade 3 Coil, Grade 3 Titanium Alloy Shim Stock, (3.7055) Cp Ti Gr.3 Foil Sheet, Ti R50550 Perforated Sheet at Best price
Examining for best cost of Titanium Alloy Grade 3 Plate in India? We have no base film prerequisites. We will supply the definite entire ofTitanium CP2 Grade 3 Coil you require paying little personality to whether it's little proportion of Grade 3 Titanium Alloy Shim Stock. Contact Steel Tubes India-the advantage supplier of Cp Ti Grade 3 Coil Sheet close to you.
We offers apparently the most released up broaden ofTitan-Grade 3 Flat Sheet (3.7055) and Ti Grade 3 R50550 Perforated Sheet in different qualities, sizes and levels which are unclear to Titanium level 3 Sheet & Titanium level 3 Plate (2mm to 12mm). Titanium grade 3 Sheet is open in thicknesses loosening up from .016 to .156". Immense size Titanium grade 3 plate will likewise reduce the size of the bothersome warmth influenced zone acknowledged by welding. We in like way stock & supply extra immense size Titanium grade 3 Sheets, weak and ultra-slim measure Ti. Mix Grade 3 strip and foil things, plunged to 2 microns.
Extraordinary improvement correspondingly as far reaching quality control from steelmaking to completing guarantee the constant arrangement of Ti Grade 3 R50550 Perforated Sheet in dependably of stunning quality. We apply the arrangement of surface completing to our CP Grade 3 Titanium Rolling Sheet by pickling or buff-cleaning. SB 265 gr 3 Strips levels of completing & cut can be balanced by your necessities.
Titanium grade 3 Plate is accessible as Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Titanium grade 3 Plate Weight Calculatorallows you to discover a check of the hugeness of various sizes of Cp Titanium Grade 3 Thin Sheet subject to estimations and shape. These sheets are sold in either 300mm or 600mm rolls and sheet structure. The thin material can be utilized in control plants, atomic plants or gas and oil refineries.
Titanium grade 3 Coils Specifications
Standards : |
UNS R50550/ASTM B265 |
Grade : |
Titanium GR-3 (UNS R50550) |
Type : |
Coils, Strips, Flats |
Range: |
0.3mm to 150mm |
Form: |
Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
Hardness: |
Soft, Hard, Half Hard, Spring Hard, etc. |
Finish: |
Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
Other services: |
Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
Titanium Gr 3 Coil Chemical Composition
| Element | Percent by Weight | |
|---|---|---|
| N | Nitrogen | 0.05% max |
| C | Carbon | 0.08% max |
| O | Oxygen | 0.35% max |
| Fe | Iron | 0.30% max |
| H | Hydrogen | 0.015% max |
| Ti | Titanium | Remainder |
| - | Res. Each | 0.1% max |
| - | Res. Total | 0.4% max |
Titanium Gr 3 Coils Mechanical Properties
|
UTS Ksi (MPa) |
.02% YS Ksi (MPa) |
%El |
%RA |
|---|---|---|---|
|
85 (595) |
65 (450) |
25 |
48 |
Titanium Gr 3 Coils physical Properties
|
Physical Property |
T (°F) |
T (°C) |
Value |
Value (SI) |
|---|---|---|---|---|
|
Density |
|
|
0.163 lb/in3 |
4.512 g/cm3 |
|
Beta Transus |
1690 |
|
|
|
|
Thermal Conductivity |
|
|
151.2 Btu-in/hr-ft²- °F |
|
|
Electrical Resistivity |
|
|
21 ???in |
.53 ???m |
|
Magnetic Permeability |
|
|
Nonmagnetic |
|
|
Mean Coefficient of |
68-212 |
20-100 |
4.8x10¯?in in¯¹°F¯¹ |
8.6x10¯?m m¯¹°C¯¹ |
|
Thermal Expansion |
68-572 |
20-300 |
5.3x10¯?in in¯¹°F¯¹ |
9.5x10¯?m m¯¹°C¯¹ |
|
68-932 |
20-500 |
5.4x10¯?in in¯¹°F¯¹ |
9.7x10¯?m m¯¹°C¯¹ |
|
|
Elastic Modulus |
|
|
15.2-17.4 Msi |
|
Titanium Grade 3 Coils Applications
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
