LDX 2101 (UNS S32101) is a 21.5% chromium, 5% manganese, 1.5% nickel, 0.45% molybdenum lean duplex stainless steel with corrosion resistance superior to 304L and comparable to 316L. LDX 2101 possesses both superior strength and greater chloride stress-corrosion cracking resistance than conventional 300 series stainless steels.The enhanced mechanical strength of LDX 2101 enables it to be used in thinner cross-sections which can provide significant cost savings to the end user. LDX 2101 was designed to be a low nickel general purpose substitute for 304 and 304L.
Padmavati Steel & Engg.Co. is one of the greatest exporter, creator and supplier of Duplex Steel UNS S3210 Round Bars in India. Our Duplex Steel UNS S32101 Bars (generally called Duplex Steel LDX 2101 Round Bars) has unimaginable utilization deterrent against general utilization, stress disintegration breaking, disintegration fatigue, setting, crevice and crumbling disintegration.
DUPLEX STEEL 2101 is a low-nickel, nitrogen overhauled lean duplex tempered steel delivered for comprehensively helpful use. The austenitic-ferritic (duplex) structure of the compound is acclimated to around proportional proportions of ferrite and austenite in the game plan toughened condition.
The high chromium and nitrogen substance of DUPLEX STEEL 2101, got together with a development of molybdenum, give great assurance from confined and uniform disintegration. The duplex microstructure adds to the amalgams high caliber and assurance from chloride stress-utilization breaking. DUPLEX STEEL 2101 has both pervasive quality and more significant chloride weight utilization parting restriction than customary 300 course of action treated steels.
The utilization resistance of DUPLEX STEEL 2101 is regularly extraordinary making it sensible for use in a wide variety of employments. Much of the time, it is superior to anything 304L tempered steel and like the molybdenum containing 316L solidified steel.
The updated mechanical nature of DUPLEX STEEL 2101 is obviously better than customary 300 course of action tempered steels enabling it to be used in progressively slim cross-sections which can give enormous cost hold assets to the end customer.
DUPLEX STEEL 2101 presentations extraordinary scratched spot and breaking down resistance and can be made using standard shop practices created for duplex tempered steels.
Duplex 2101 Round Bar Specification
| Specifications | : | ASTM A276, A479 / ASME SA276, SA479 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size |
: | 6 mm to 120 mm. |
| Diameter |
: | 6mm to 350mm Diameter |
| Thickness | : | 100 to 6000 mm Length |
| Tolerance |
: | +/-0.2mm |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Duplex 2101 Round Bar Chemical Compositions
| Element | Value | Element | Value |
|---|---|---|---|
| Chromium | 21.0 min. - 22.0 max. | Nickel | 1.35 min. - 1.70 max. |
| Manganese | 4.00 min. - 6.00 max. | Molybdenum | 0.10 min. - 0.80 max. |
| Nitrogen | 0.20 min. - 0.25 max. | Chromium | 0.040 max. |
| Silicon | 1.00 max. | Phosphorus | 0.040 max. |
| Copper | 0.10 min. - 0.80 max. | Nitrogen | 0.030 max. |
| Iron | Balance* |
Duplex 2101 Round Bar Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel 2101 | 1.4162 | S32101 |
Duplex 2101 Round Bar Mechanical Properties
| Minimum values (.625" Plate) |
Typical values (.625" Plate) |
||
|---|---|---|---|
| 0.2% Offset Yield Strength | ksi | 65 | 69 |
| Tensile Strength | ksi | 94 | 101 |
| Elongation | % | 30 | 38 |
| Hardness (Brinell) | HB | 290 (max) | 225 |
Duplex 2101 Round Bar Physical Properties
| Temperature, °F | |||||
|---|---|---|---|---|---|
| 68 | 200 | 400 | 600 | ||
| Density | lb/in3 | 0.28 | |||
| Modules of Elasticity | x 10sup>6 psi | 29 | 28 | 27 | 26 |
| Poissons Ratio | 0.3 | ||||
| Linear Expansion | x 10-6 in/in/°F | — | 7.2 | 7.5 | 7.5 |
| Thermal Conductivity | Btu/ft/h °F | 8.7 | 9.3 | 9.8 | 10.4 |
| Thermal Capacity | J/kg °F | 500 | 530 | 560 | 590 |
| Electric Resistivity | micro-ohms•meter | 0.80 | 0.85 | 0.90 | 1.00 |
Duplex 2101 Round Bar Applications
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceutical
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
