Alloy 2304 (UNS S32304) is a 23% chromium, 4% nickel, molybdenum-free duplex stainless steel. The Alloy 2304 has corrosion resistance properties similar to 316L. Furthermore, its mechanical properties, i.e., yield strength, are twice those of 304L/316L austenitic grades. This allows the designer to save weight, particularly for properly designed pressure vessel applications.
Padmavati Steel & Engg.Co. is one of the greatest exporter, creator and supplier of Duplex Steel UNS S3210 Round Bars in India. Our Duplex Steel 2304 Bars has unimaginable utilization deterrent against general utilization, stress disintegration breaking, disintegration fatigue, setting, crevice and crumbling disintegration.
Duplex Steel 2304 Tubes with 25% chromium, 4% molybdenum, and 7% nickel planned for mentioning applications which require superb quality and disintegration resistance, for instance, substance methodology, petrochemical, and seawater equipment. The steel has radiant insurance from chloride stress utilization breaking, high warm conductivity, and a low coefficient of warm advancement. The high chromium, molybdenum, and nitrogen levels give astounding insurance from setting, opening, and general disintegration.
Mix 2304 is a 23% chromium, 4% nickel, sans molybdenum duplex tempered steel. The Alloy 2304 has disintegration impediment properties like 316L. In addition, its mechanical properties, i.e., yield quality, are twice those of 304/316 austenitic assessments. This empowers the originator to extra weight, particularly for fittingly arranged weight vessel applications.
The Alloy is particularly suitable for applications covering the - 50°C/+300°C (- 58°F/572°F) temperature expand. Lower temperatures may in like manner be considered at this point need a couple of confinements, particularly for welded structures.
With its duplex microstructure and low nickel and high chromium substance, the compound has improved weight disintegration restriction properties stood out from 304 and 316 austenitic assessments.
Duplex 2304 Round Bar Specification
| Specifications | : | ASTM A276, A479 / ASME SA276, SA479 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size |
: | 6 mm to 120 mm. |
| Diameter |
: | 6mm to 350mm Diameter |
| Thickness | : | 100 to 6000 mm Length |
| Tolerance |
: | +/-0.2mm |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Duplex 2304 Round Bar Chemical Compositions
| Carbon | Chromium | Nickel | Molybdenum | Nitrogen | Others |
|---|---|---|---|---|---|
| 0.020 | 23 | 4 | 0.2 | 0.1 | S=0.001 |
| PREN = [Cr%] = 3.3 [Mo%] = 16 [N%] ≥ 24 | |||||
Duplex 2304 Round Bar Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel 2101 | 1.4162 | S32304 |
Duplex 2304 Round Bar Mechanical Properties
| °C | Rp 0.2 MPa |
Rp 1.0 MPa |
Rp 1.0 MPa |
°F | YS 0.2% Offset KSI |
YS 0.1% Offset KSI |
UTS KSI |
Elongation % |
|---|---|---|---|---|---|---|---|---|
| 20 | 400 | 440 | 600 | 68 | 58 | 64 | 87 | 25 |
| 100 | 330 | 365 | 570 | 212 | 48 | 53 | 83 | 25 |
| 200 | 280 | 310 | 530 | 392 | 41 | 45 | 77 | 20 |
| 300 | 230 | 260 | 490 | 572 | 33 | 38 | 71 | 20 |
Duplex 2304 Round Bar Physical Properties
| Interval Temper °C |
Thermal expansion ax10M-bK-1 |
°C |
Resistivity (μ_ cm) |
Thermal conductivity (W.m-1.K-1) |
Specific heat (J.kg-1.K-1 |
Young modulus E (GPa) |
Shear modulus G (GPa) |
|---|---|---|---|---|---|---|---|
| 20-100 | 13 | 20 | 80 | 17 | 450 | 200 | 75 |
| 20-100 | 13 | 100 | 92 | 18 | 500 | 190 | 73 |
| 20-200 | 13.5 | 200 | 100 | 19 | 530 | 180 | 70 |
| 20-300 | 14 | 300 | 105 | 20 | 560 | 170 | 67 |
Duplex 2304 Round Bar Applications
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceutical
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
