Alloy UNS S32304 is a 23% chromium, 4% nickel, molybdenum-free duplex stainless steel. The Alloy 2304 has corrosion resistance properties similar to 316L. Furthermore, its mechanical properties, i.e., yield strength, are twice those of 304L/316L austenitic grades. This allows the designer to save weight, particularly for properly designed pressure vessel applications.

Padmavati Steel & Engg.Co. is one of the greatest exporter, creator and supplier of Duplex Steel UNS S32304 Round Bars in India. Our Duplex Steel S32304 Bars has unimaginable utilization deterrent against general utilization, stress disintegration breaking, disintegration fatigue, setting, crevice and crumbling disintegration.

Duplex Steel S32304 Tubes with 25% chromium, 4% molybdenum, and 7% nickel planned for mentioning applications which require superb quality and disintegration resistance, for instance, substance methodology, petrochemical, and seawater equipment. The steel has radiant insurance from chloride stress utilization breaking, high warm conductivity, and a low coefficient of warm advancement. The high chromium, molybdenum, and nitrogen levels give astounding insurance from setting, opening, and general disintegration.

Mix S32304 is a 23% chromium, 4% nickel, sans molybdenum duplex tempered steel. The Alloy 2304 has disintegration impediment properties like 316L. In addition, its mechanical properties, i.e., yield quality, are twice those of 304/316 austenitic assessments. This empowers the originator to extra weight, particularly for fittingly arranged weight vessel applications.

The Alloy is particularly suitable for applications covering the - 50°C/+300°C (- 58°F/572°F) temperature expand. Lower temperatures may in like manner be considered at this point need a couple of confinements, particularly for welded structures.

With its duplex microstructure and low nickel and high chromium substance, the compound has improved weight disintegration restriction properties stood out from 304 and 316 austenitic assessments.

Duplex S32304 Round Bar Specification

Specifications	:	ASTM A276, A479 / ASME SA276, SA479
Dimensions	:	EN, DIN, JIS, ASTM, BS, ASME, AISI
Size	:	6 mm to 120 mm.
Diameter	:	6mm to 350mm Diameter
Thickness	:	100 to 6000 mm Length
Tolerance	:	+/-0.2mm
Finish	:	Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Length	:	1 to 6 Meters, Custom Cut Lengths
Form	:	Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.

Duplex S32304 Round Bar Chemical Compositions

Carbon	Chromium	Nickel	Molybdenum	Nitrogen	Others
0.020	23	4	0.2	0.1	S=0.001
PREN = [Cr%] = 3.3 [Mo%] = 16 [N%] ≥ 24

Duplex S32304 Round Bar Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS
Duplex Steel 2101	1.4162	S32304

Duplex S32304 Round Bar Mechanical Properties

°C	Rp 0.2 MPa	Rp 1.0 MPa	Rp 1.0 MPa	°F	YS 0.2% Offset KSI	YS 0.1% Offset KSI	UTS KSI	Elongation %
20	400	440	600	68	58	64	87	25
100	330	365	570	212	48	53	83	25
200	280	310	530	392	41	45	77	20
300	230	260	490	572	33	38	71	20

Duplex 2304 Round Bar Physical Properties

Interval Temper °C	Thermal expansion ax10M^-bK^-1	°C	Resistivity (μ_ cm)	Thermal conductivity (W.m^-1.K^-1)	Specific heat (J.kg^-1.K^-1	Young modulus E (GPa)	Shear modulus G (GPa)
20-100	13	20	80	17	450	200	75
20-100	13	100	92	18	500	190	73
20-200	13.5	200	100	19	530	180	70
20-300	14	300	105	20	560	170	67

Duplex S32304 Round Bar Applications

Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceutical
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry
