In the market, you will get the proportions of Stainless Steel 316L Sheets and Plates exporters among them Padmavati Steel & Engg.Co. is said to be the best one exporter since they use to make each and every best grade of plates and steel. Here in this article, we will see its best quality material that is Stainless Steel 316L Sheets and Plates. It is made by using the latest structures that make the thing unbelievable and formed it eminently from all sides. It even uses to give the perfect finishing to the thing. This plates and steels are reliably strong and trustworthy on the other hand with various types of steels grades.
They make the thing as per the referenced guidelines that ensure the standard of the thing. These evaluation materials can certainly be dealt with no uneasiness. This thing can without a lot of a stretch be upheld in the crazy cools since it has the best deterrent breaking point that makes it strong to be used in a mechanical applications. It can work in low and high both kind of temperature all such intricacy in the air condition don't influence the thing quality in light of how the compound which is used in it making is of respect types and makes its readied to be used it wherever in endeavors.
The Stainless Steel 316L Sheets and Plates come in different estimations and shapes by virtue of which customer get the one which they need for their endeavors. They are even exceptional in nature, strong and mindful treated steel. You will in like manner find its usage in the marine relationship in setting on its high bore and ruinous properties.
Stainless Steel 316L Sheet and Plate Specification
Standard : ASTM / ASME A240 / SA240
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness :0.01 mm to 250 mmThk
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Equivalent Grades of SS 316L Sheet and Plate
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17-11-02 / Z3CND18-14-03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L Sheet & Plate Chemical Composition
| Element | SS 316L |
| C | 0.035 max |
| Mn | 2.0 max |
| Si | 1.0 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16 – 18 |
| Ni | 10 – 14 |
| Mo | 2 – 3 |
| Fe | 68.89 min |
Mechanical Properties of SS 316L Sheet and Plate
| Element | SS 316L |
| Density | 8.0 g/cm3 |
| Melting Point | 1399 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
